MIL-D-52916A(ME)
TABLE I. Electrical system - Continued.
Description
Requirement
Quantity
Blackout combination lamps,
Military type,
2 ea.
rear
MS51330
Reflectors
MS35387
8 ea., min.
Low tension cable
MIL-C-13486, 14
AR
A.W.G. Min.
Harness insulation
MIL-I-631 & MIL-I-15126
AR
Loom
Semitrailer type
AR
polyethylene tubing or oil
proof SAE J562 loom
Conduit
Commercial, thinwall type
AR
Cushioned support clamps
MS21322, MS21333,
AR
MS21334
Circuit number bands
MIL-B-43436 &
AR
MIL-B-43436/1
Friction connectors
MS 27142 through
AR
MS27148 & MS33800
waterproof
Connector lubricant
MIL-S-8660
AR
Connector holder clip
Plastic or spring clip,
AR
similar to MIL-C-24066 &
MIL-C-24066/2-329
Terminal connectors
Spade type per SAE J561
AR
with heat Shrinkable or
integral insulator sleeves
Hazard warning signal
DOT Regulations, SAE
1 assy
J910, and SAE J945
3.20.1 Wiring. The wiring for both the service and blackout light systems shall be in
accordance with the figure furnished by the contracting officer (see 3.26 and 6.4). The wiring
shall be protected from road splash. The wiring jacket shall not be fabricated from poly vinyl
chloride (PVC). Cushion clamps, loom, thinwall conduit and grommets shall be provided to
prevent whipping, chafing and other mechanical and heat damage. Wiring shall be fastened to
the frame at intervals not to exceed 3 feet (.9144 m). Two or more cables following the same
routing shall be enclosed in loom or conduit having each end waterproofed, or shall be bound
together in harness with 0.5 overlapping wraps of plastic tape. Splices shall be waterproofed.
Mechanical splicing devices , if used, shall be fastened to the frame members with the interior of
the device waterproofed with silicon sealant. All connections shall be varnished according to
MIL-V-173. All circuits shall be identified by number coding as specified in the Government
furnished diagrams (see 3.26 and 6.4). The circuit number bands shall be installed near each
connection. The mating surfaces of the elastomer friction connectors shall be sealed with silicon
sealant prior to assembly. The assembled friction connectors shall be secured to the frame with
12
